JVM

Type	Oscillation	Effective	Overshoot	Mass
Type	Frequency [Hz]	weight [kg]	[mm]	[kg]
JD 20-50	50	0.3-2.0	2.15-1.45	3.9
JD 20G-50	50	2.1-2.8	1.45-1.20	6.8
JD 30-50	50	1.5-4.5	2.00-1.45	7.3
JD 30G-50	50	4.6-6.0	1.45-1.20	12
JD 40-50	50	2.5-8.3	2.00-1.45	13.4
JD 40G-50	50	8.4-10.5	1.45-1.20	20.1
JD 50-50	50	6.0-15.4	1.90-1.45	25.5
JD 50G-50	50	15.5-22.0	1.45-1.15	37.7
JD 20-60	60	0.3-1.9	1.75-1.25	3.9
JD 20G-60	60	2.0-2.8	1.25-1.00	6.8
JD 30-60	60	1.5-4.2	1.55-1.15	7.3
JD 30G-60	60	4.3-6.0	1.15-0.90	12
JD 40-60	60	2.5-8.5	1.60-1.15	13.4
JD 40G-60	60	8.6-10.5	1.15-1.00	20.1
JD 50-60	60	6.0-16.3	1.50-1.10	25.5
JD 50G-60	60	16.4-22.0	1.10-0.97	37.7
JDA 20-50	50	0.3-2.0	2.15-1.45	3.9
JDA 20G-50	50	2.1-2.8	1.45-1.20	6.8
JDA 30-50	50	1.5-4.5	2.00-1.45	7.3
JDA 30G-50	50	4.6-6.0	1.45-1.20	12
JDA 40-50	50	2.5-8.3	2.00-1.45	13.4
JDA 40G-50	50	8.4-10.5	1.45-1.20	20.1
JDA 50-50	50	6.0-15.4	1.90-1.45	25.5
JDA 50G-50	50	15.5-22.0	1.45-1.15	37.7
JDA 20-60	60	0.3-1.9	1.75-1.25	3.9
JDA 20G-60	60	2.0-2.8	1.25-1.00	6.8
JDA 30-60	60	1.5-4.2	1.55-1.15	7.3
JDA 30G-60	60	4.3-6.0	1.15-0.90	12
JDA 40-60	60	2.5-8.5	1.60-1.15	13.4
JDA 40G-60	60	8.6-10.5	1.15-1.00	20.1
JDA 50-60	60	6.0-16.3	1.50-1.10	25.5
JDA 50G-60	60	16.4-22.0	1.10-0.97	37.7
JDE 20-50	50	0.3-2.0	2.15-1.45	3.9
JDE 30-50	50	1.5-4.5	2.00-1.45	7.3
JDE 40-50	50	2.5-8.3	2.00-1.45	13.4
JDE 50-50	50	6.0-15.4	1.90-1.45	25.5

Type	Oscillation	Effective	Overshoot	Mass	Control
Type	Frequency [Hz]	weight [kg]	[mm]	[kg]	[at 400V]
MS 6-50	50	102-255	2.0-1.0	130	JT 14 (230V: JT26)
MS 50-50	50	158-380	1.1-0.5	92	JT 14
MS 5-50	50	53-155	2.1-1.0	88	JT 14
MS 40-50	50	85-189	1.0-0.5	57	JT 14
MS 4-50	50	30-89	2.0-0.9	53	JT 14
MS 30-50	50	44-153	1.2-0.4	44	JT 14
MS 3-50	50	16-48	2.0-1.0	42	JT 14
MS 8-30	30	204-517	3.2-1.6	290	JT 45
MS 6-30	30	93-230	3.3-1.6	120	JT 14
MS 5-30	30	55-135	3.4-1.7	78	JT 14
MS 4-30	30	33-93	3.3-1.5	51	JT 14
MS 3-30	30	15-52	3.2-1.5	39	JT 14
MS 8-60	60	215-570	1.7-0.8	224	JT 26
MS 7-60	60	160-345	1.7-0.9	135	JT 14
MS 60-60	60	225-570	1.0-0.4	140	JT 14
MS 6-60	60	115-251	1.5-0.8	140	JT 14
MS 50-60	60	153-380	1.1-0.5	102	JT 14
MS 5-60	60	63-153	1.7-0.9	95	JT 14
MS 40-60	60	82-190	0.9-0.5	62	JT 14
MS 4-60	60	37-82	1.5-0.8	58	JT 14
MS 30-60	60	43-153	1.2-0.4	50	JT 14
MS 3-60	60	16-45	1.7-0.9	45	JT 14
MS 10-25	25	600-1300	3.8-2.1	680	JT 70
MS 8-25	25	190-450	4.2-2.4	285	JT 45 (500V: JT26)
MS 6-25	25	82-230	4.4-2.0	110	JT 14 (230V: JT26)
MS 5-25	25	47-135	5.1-2.3	75	JT 14
MS 4-25	25	33-93	4.0-1.8	50	JT 14
MS 3-25	25	13-48	4.0-1.9	37	JT 14
MS 10-50	50	570-1300	1.7-0.9	695	JT 45
MS 80-50	50	580-1300	1.0-0.5	310	JT 26
MS 8-50	50	210-520	2.1-1.1	296	JT 26
MS 70-50	50	280-760	1.2-0.5	134	JT 14
MS 7-50	50	130-305	2.2-1.1	134	JT 14
MS 60-50	50	230-570	1.1-0.5	130	JT 14 (230V: JT26)
MSA 3-50	50	16-48	2.0-1.0	42	JT 14
MSA 3-60	60	16-45	1.7-0.9	45	JT 14
MSA 30-50	50	44-153	1.2-0.4	44	JT 14
MSA 4-50	50	30-89	2.0-0.9	53	JT 14
MSA 4-60	60	37-82	1.5-0.8	58	JT 14
MSA 5-25	25	47-135	5.1-2.3	75	JT 14
MSA 5-30	30	55-135	3.4-1.7	78	JT 14
MSA 5-50	50	53-155	2.1-1.0	88	JT 14
MSA 5-60	60	63-153	1.7-0.9	95	JT 14
MSA 50-50	50	158-380	1.1-0.5	92	JT 14
MSA 50-60	60	153-380	1.1-0.5	102	JT 14
MSA 6-25	25	82-230	4.4-2.0	110	JT 14 (230V: JT26)
MSA 6-30	30	93-230	3.3-1.6	120	JT 14
MSA 6-50	50	102-255	2.0-1.0	130	JT 14 (230V: JT26)
MSA 6-60	60	115-251	1.5-0.8	140	JT 14
MSA 60-50	50	230-570	1.1-0.5	130	JT 14 (230V: JT26)
MSA 7-50	50	130-305	2.2-1.1	134	JT 14
MSA 70-50	50	280-760	1.2-0.5	134	JT 14
MSA 8-25	25	190-450	4.2-2.4	285	JT 45 (500V: JT26)
MSA 8-50	50	210-520	2.1-1.1	296	JT 26
MSA 8-60	60	215-570	1.7-0.8	224	JT 26
MSA 80-50	50	580-1300	1.0-0.5	310	JT 26
MSC 3-60	60	16-45	1.7-0.9	45	JT 14
MSC 4-30	30	33-93	3.3-1.5	51	JT 14
MSC 4-60	60	37-82	1.5-0.8	58	JT 14
MSC 40-60	60	82-190	0.9-0.5	62	JT 14
MSC 5-30	30	55-135	3.4-1.7	78	JT 14
MSC 5-60	60	63-153	1.7-0.9	95	JT 14
MSC 50-60	60	153-380	1.1-0.5	102	JT 14
MSC 6-60	60	115-251	1.5-0.8	140	JT 14
MSC 60-60	60	225-570	1.0-0.4	140	JT 14
MSC 7-60	60	160-345	1.7-0.9	135	JT 14
MSC 8-60	60	215-570	1.7-0.8	224	JT 26


Type	Working	Centrifugal	Number of	Power	Mass
	Moment	[kN]	Revolutions	[kW]	[kg]
	[kgcm]		[min-1]
JX 072-1	1	0.5	3600	0.15	6.5
JX 082-2,8	2.8	2	3600	0.15	9
JX 102-10	10	6.9	3600	0.45	23
JX 132-28	28	19.7	3600	0.85	45
JX 072-1	1	0.5	3000	0.15	6.5
JX 082-4	4	2	3000	0.15	9
JX 102-14	14	6.9	3000	0.45	23
JX 132-40	40	19.7	3000	0.85	45
JX 084-8,5	8.5	1.5	1800	0.15	12
JX 084-14	14	2.5	1800	0.15	15.6
JX 104-35	35	6.2	1800	0,4	27
JX 134-46	46	8	1800	0.8	41.5
JX 134-63	63	11.2	1800	0.8	45.5
JX 154-90	90	16	1800	1.2	74
JX 154-130	130	23.4	1800	1.2	78
JX 174-140	140	24.9	1800	1.6	91
JX 184-200	200	37.2	1800	2,5	110
JX 244-270	270	48.7	1800	3,1	174
JX 244-330	330	59.72	1800	3,8	198.5
JX 284-440	440	78.2	1800	6	282
JX 284-490	490	88.1	1800	6	286
JX 284-600	600	107.7	1800	5,8	319
JX 084-12	12	1.5	1500	0.15	12
JX 084-20	20	2.5	1500	0.15	15.6
JX 104-50	50	6.2	1500	0,4	27
JX 134-66	66	8	1500	0.8	41.5
JX 134-90	90	11.2	1500	0.8	45.5
JX 154-130	130	16	1500	1.2	74
JX 154-190	190	23.4	1500	1.2	78
JX 174-200	200	24.9	1500	1.6	91
JX 184-300	300	37.5	1500	2,2	116
JX 244-390	390	49	1500	3	181
JX 244-490	490	60.82	1500	3,5	207
JX 284-630	630	78.6	1500	5,4	293
JX 284-710	710	88.6	1500	5,4	297
JX 284-900	900	112	1500	5,5	333
JX 106-70	70	5.5	1200	0.38	32.5
JX 136-125	125	9.9	1200	0.65	56
JX 156-175	175	13.8	1200	0.95	76
JX 156-230	230	18.1	1200	0.95	85
JX 176-310	310	24.7	1200	1.6	122
JX 176-380	380	30.1	1200	1.6	132
JX 186-500	500	39.86	1200	2.4	151.5
JX 206-620	620	49.17	1200	2.6	185
JX 246-660	660	52.12	1200	3.4	203
JX 246-820	820	65	1200	4	234.5
JX 286-900	900	71.7	1200	4.4	299
JX 286-980	980	77.4	1200	5.1	309
JX 286-1180	1180	93.2	1200	5.1	344
JX 286-1540	1530	120.8	1200	6.7	395
JX 306-1800	1800	142.2	1200	8.3	520
JX 306-2100	2100	166.7	1200	8.3	560
JX 106-100	100	5.5	1000	0.38	32.5
JX 136-180	180	9.9	1000	0.65	56
JX 156-250	250	13.8	1000	0.95	76
JX 156-330	330	18.1	1000	0.95	85
JX 176-450	450	24.7	1000	1.6	122
JX 176-550	550	30.1	1000	1.6	132
JX 186-710	710	39.04	1000	2.3	163
JX 206-820	820	45.13	1000	2.2	196
JX 246-940	940	51.82	1000	3.1	230
JX 246-1250	1250	68.76	1000	3.9	258
JX 286-1250	1250	68.8	1000	4.2	317
JX 286-1460	1460	80.06	1000	4.8	338
JX 286-1730	1730	94.8	1000	4.8	370
JX 286-2160	2150	117.9	1000	6	420
JX 306-2680	2680	147.2	1000	7.65	552
JX 306-3220	3220	176.6	1000	7.65	602
JX 158-285	285	12.7	900	0.95	95
JX 178-450	450	20.8	900	0.6	138
JX 208-820	820	36.53	900	2.5	200
JX 208-1060	1060	47.05	900	2.5	234
JX 208-1250	1250	55.84	900	3.3	250
JX 248-1260	1260	55.9	900	3.7	281
JX 248-1520	1520	67.5	900	3.7	295
JX 288-1780	1780	79.2	900	4.7	367
JX 288-2150	2150	95.4	900	5.5	404.5
JX 308-3100	3100	139.5	900	11.5	703
JX 308-3850	3850	175.3	900	11.5	766
JX 158-410	410	12.7	750	0.95	95
JX 178-675	675	20.8	750	1.6	138
JX 208-820	820	25.2	750	2.3	200
JX 208-1060	1060	32.65	750	2.3	234
JX 208-1250	1250	38.81	750	3	250
JX 248-1520	1520	46.9	750	3.1	301
JX 248-1780	1780	55	750	3.1	309
JX 288-2150	2150	66.2	750	4.2	385
JX 288-2610	2610	80.4	750	5.3	433
JX 308-3600	3600	110.9	750	10.5	722
JX 308-4300	4300	132.5	750	10.5	785
JVE 082-4	4	2	3000	0.2	9
JVC 082-2.8	2.8	2	3600	0.2	9
JVE 102-14	14	7	3000	0.5	18
JVC 102-10	10	7	3600	0.5	17
JVE 132-25	24	12	3000	0.9	28
JVC 132-18	17	12	3600	0.9	27
JVE 132-40	40	19.9	3000	0.9	35
JVC 132-28	28	19.9	3600	0.9	33
JVE 084-12	12	1.5	1500	0.2	11
JVC 084-8.5	8.5	1.5	1800	0.2	11
JVE 084-20	20	2.5	1500	0.2	14
JVC 084-14	14	2.5	1800	0.2	14
JVE 104-50	50	6.2	1500	0.4	22
JVC 104-35	35	6.2	1800	0.4	20
JVE 134-66	65	8	1500	0.6	31
JVC 134-46	45	8	1800	0.6	29
JVE 134-90	90	11.2	1500	0.8	35
JVC 134-63	63	11.2	1800	0.8	32
JVE 154-130	130	16	1500	1.2	53
JVC 154-90	90	16	1800	1.2	52
JVE 154-190	190	23.4	1500	1.2	57
JVC 154-130	130	23.4	1800	1.2	53
JVE 174-200	200	24.8	1500	1.6	73
JVC 174-140	140	24.8	1800	1.6	66
JVE 204-300	300	37.3	1500	2.8	115
JVC 204-210	210	37.3	1800	2.8	110
JVE 106-100	100	5.5	1000	0.4	27
JVC 106-70	70	5.5	1200	0.4	23
JVE 136-180	180	9.9	1000	0.7	47
JVC 136-125	125	9.9	1200	0.7	39
JVE 156-250	250	13.8	1000	1	66
JVC 156-175	175	13.8	1200	1	56
JVE 156-330	330	18.1	1000	1	75
JVC 156-230	230	18.1	1200	1	65
JVE 176-450	450	24.7	1000	1.6	105
JVC 176-310	310	24.7	1200	1.6	86
JVE 176-550	550	30.1	1000	1.6	115
JVC 176-380	380	30.1	1200	1.6	98
JVE 206-570	570	31.5	1000	2.4	126
JVC 206-400	400	31.5	1200	2.4	118
JVE 206-700	700	38.6	1000	2.4	137
JVC 206-490	490	38.6	1200	2.4	121
JVE 206-850	850	46.5	1000	2.4	149
JVC 206-570	570	46.5	1200	2.4	126
JVE 246-950	950	52.1	1000	3	204
JVC 246-660	660	52.1	1200	3	178
JVE 246-1100	1100	60.3	1000	3	217
JVC 246-780	780	60.3	1200	3	197
JVE 276-1400	1400	77	1000	6	316
JVC 276-980	980	77	1200	6	295
JVE 276-1750	1750	96	1000	6	356
JVC 276-1200	1200	96	1200	6	305
JVE 276-2050	2050	112.4	1000	6	391
JVC 276-1400	1400	112.4	1200	6	316
JVC 072-1	1	0.5	3600	0.2	4
JVE 106-50	50	2.8	1000	0.4	22
JVC 106-35	35	2.8	1200	0.4	21
JVE 246-1161	1161	65	1000	3	227
JVC 246-801	801	60.3	1200	3	199
JVC 276-900	900	71.3	1200	4	263
JVC 276-979	979	75	1200	4	280
JVC 172-42	42	29.7	3600	2.5	63
JVC 244-280	280	49.5	1800	3.6	162
JVC 274-380	380	67.8	1800	4.5	236
JVC 274-550	550	92.5	1800	7.3	259
JVC 314-700	700	124	1800	12.5	404
JVC 276-800	800	63.1	1200	4	249
JVC 316-1530	1530	120.6	1200	9.5	455
JVC 316-1900	1900	149.1	1200	9.5	485
JVC 158-285	285	12.7	900	1	72
JVC 178-450	450	20.8	900	1.6	105
JVC 208-570	570	26.4	900	2.5	126
JVC 208-700	700	32.4	900	2.5	137
JVC 208-855	855	38.6	900	2.5	150
JVC 248-1065	1065	47.5	900	3.6	221
JVC 248-1200	1200	55.5	900	3.6	240
JVC 278-1400	1400	64.8	900	6	316
JVC 278-1750	1750	81	900	6	356
JVC 318-2200	2200	101.6	900	6.8	500


Type	Working	Centrifugal	Number of	Mass
	Moment	[kN]	Revolutions	[kg]
	[kgcm]		[min-1]
JR 208	2600-4300	100-155	830	550
JR 406	1600-4400	90-240	1000	730
JR 408	3900-6700	145-240	830	800
JR 606	2700-6000	150-330	1000	970
JR 608	5700-9100	215-330	830	1110
JR 816	3000-8400	165-460	1000	1270
JR 818	7000-12400	265-460	830	1440
JR 1018	10400-20400	320-630	750	2500
JR 206	1100-2800	60-155	1000	470
